Zenitron DC-DC PoE Module 30W

Solution Feature Description

1. 37V to 57V Input range Non-isolated Flyback converter with 30W of output power
2. VIN UVLO configured to 42V (rising edge), 36V (falling edge)
3. The evaluation board is configured to operate at 200kHz switching frequency
4. 54V at 0.6A output
5. Efficiency up to 86% @54V 0.6A
6. Fully IEEE802.3af-2003 and IEEE802.3at-2009 compliant
7. Supports 2 Pairs and 4 Pairs (Data and Spare Power Feeding)
8. Over-temperature protection
9. Wide temperature range: -40° to +85° C

1. IEEE802.3at and IEEE802.3af powered devices such as IP phones, WLAN Access Points and Network Cameras.
2. 48V Input Telcom/Networks Hot Swappable Power Supply.

1. 37V to 57V Input range
2. 54V at 0.6A output
3. Fully IEEE802.3af-2003 and IEEE802.3at-2009 compliant
4. Configurable AT/AF modes
5. Option : for 7W power limit
